1.1.1 Machine Parameters | |
Product parameters | Description |
Hardware platform | EG915U-CN/EU/LA+AT6558R(GPS+BD) |
Device size | 80x 36x 15mm |
GPS antenna | Built-in 25mm*25mm*4mm ceramic antenna |
Positioning method | GPS/BDS/GLONASS & LBS |
Power input | 9~90VDC |
Vibration sensor | Support |
Battery installation | Support |
Battery capacity | 55mAh |
Oil and power off | Support |
Power status indicator | Red |
GPS status indicator | Blue |
Network status indicator | Green |
ACC ignition detection | Support |
Working mode | Long connection |
SMS | Support |
Communication antenna | FPC antenna |
Communication network | CAT1 |
Communication method | TCP |
Working temperature | -20℃~ +70℃ |
Storage temperature | -25℃~ +75℃ Best (0℃~ +30℃) |
Positioning error | GPS positioning error <10m (actual positioning error is related to factors such as the vehicle's regional environment and weather). |
Base station positioning error depends on the current base station coverage information. | |
1.1.2 Network Performance | |
Support Mode | 4G-LTE-CAT1 |
Frequency band CN (optional) | FDD B1/ 3/ 5/ 8 |
TDD B34/ 38/ 39/ 40/ 41 | |
GSM900/1900MHz | |
Frequency band EU (optional) | FDD B1/ 3/ 5/ 7/ 8/ 20/ 28 |
GSM850/900/1800MHz/1900MHz | |
Frequency band LA (optional) | FDD B2/ 3/ 4/ 5/ 7/ 8/ 28/ 66 |
GSM850/900/1800MHz/1900MHz | |
1.1.3 GPS Performance | |
Positioning type | GPS/BDS/GLONASS |
Signal reception | Support GPS/BDS/GLONASS parallel reception and joint positioning |
Cold start TTFF | ≤35S |
Hot start TTFF | ≤1S |
Recapture TTFF | ≤1S |
Cold start capture sensitivity | -147dBm |
Recapture sensitivity | -157 dBm |
Tracking sensitivity | -160dBm |
Positioning accuracy | ≤10M |
Speed measurement accuracy | <0.1m/s |
Timing accuracy | <30ns |
Positioning update rate | Maximum 5Hz |
AGPS | Support |
2 Functional Description | |
2.1 Indicator Light Description | |
Network mode light (yellow light) | Status definition |
Fast flash | Network signal initialization |
Slow flash | Network signal reception is normal |
Off | Network signal not found or in sleep mode |
GPS signal light (blue light) | Status definition |
Fast flash | GPS signal search in progress |
Slow flash | GPS positioned |
Off | GPS signal not found or in sleep mode |
POWER light (red light) | Status definition |
Slow flash | Normal operation with battery power alone |
Still on | Normal operation with external power supply |
Off | Device failure or in sleep mode |
2.2 Functional Description | |
Function details | Functional Description |
Speeding alarm | Overspeed alarm default: Off; when the speed exceeds the set threshold, an overspeed alarm is uploaded. |
Electronic fence | Fence alarm default: Off; when the terminal exceeds the set fence, a fence alarm will be generated |
Vibration alarm | The default setting of vibration alarm is off. The steps to set the vibration alarm are as follows: |
Turn on the vibration alarm → the device is in a stationary state, and after 10 minutes the device enters the defense state → vibrates 3 times within 10 seconds → delay 1 minute → upload the vibration alarm! | |
Displacement alarm | Turn on the displacement alarm → After the device stops (ACC OFF) and enters the sleep state → Drive again to the set displacement distance → Generate a displacement alarm |
2. When the vehicle moves a set distance, the platform receives a displacement alarm. If the alarm mode is selected with SMS alarm and an SOS number is set, the SOS number will receive the corresponding SMS or phone alarm of the displacement alarm. | |
Low battery alarm | The default setting for low battery alarm is: On, disconnect the external power for 5 minutes, and then upload the low battery alarm. |
Disconnect/restore oil and electricity | ACC ON or OFF state, the device is in positioning state, the vehicle speed is less than 20KM/H, if the vehicle speed is greater than 20KM/H, it will be delayed until the conditions are met! |
1. Disconnect the oil and electricity: Send the command on the platform: Disconnect the oil and electricity or send the SMS command: RELAY, 1#, the terminal replies: The oil and electricity are disconnected successfully! Speed: 0 km/h | |
2. Restore oil and electricity: Send command on the platform: Restore oil and electricity or SMS command: RELAY, 0#, the terminal replies: Restore oil and electricity successfully! | |
Power failure alarm | After the device is disconnected from the external power supply, it will send out a power failure alarm within 30 seconds. |
Note: If the battery voltage is above 3.8V, the switch must be turned on. | |
Model No./ P4 Device Type In-car Device Dimension 60*35*15mm Device Weight 75g Telecom Chipset Mediatek MT2503D Network GSM&GPRS Frequency Band GSM 850/900/1800/1900MHz Location Chipset MT2503 Location Way LBS/AGPS/GPS/Glonass/BD Location accuracy <10 meters Tracking sensitivity -159 dBm TTFF (open sky) Cold status 35-80s Warm status 35s Hot status 1s Storage Temp -40°C to +85°C Operation Temp -20°C to +55°C Humidity 5%--95% non-condensing Internal Battery 1500mah Standby Time 90 days Working voltage(vehicle tracker) 9-90V working voltage/current 200MA Charger (Non-vehicle tracker) magnet no Sim Card middle Box Dimension 143X96X36MM Box Weight 60g Carton Dimension(XXpcs) Carton Weight(XXpcs) Functions Real-time tracking, historical track, electronic fence, power failure alarm, remote listening, recording, remote oil and power failure, vibration alarm
