Product parameters | Description | |
Hardware platform | N58+Hexinxingtong (UC6228) | |
Positioning method | GPS/BDS/GLONASS &LBS | |
Positioning error | GPS positioning error <10m (the actual positioning error is related to factors such as the vehicle's regional environment and weather). Base station positioning error depends on the current base station coverage information. | |
GSM antenna | Shrapnel antenna | |
GPS antenna | Built-in 25*25*4mm ceramic antenna | |
Light sensor | Support | |
WIFI | Not support | |
Vibration sensor | Support | |
Microphone | Support | |
SMS | Support | |
Power switch | Built-in button | |
Battery installation | Welding | |
Communication network | FDD-LTE CAT1/TDD-LTE CAT1 | |
Communication method | TCP | |
Waterproof and dustproof | IP65 | |
Operating temperature | -25℃~+75℃ | |
Storage temperature | -35℃~+80℃ | |
1.1.2 Network Performance | ||
Support Mode | FDD-LTE(Cat 1)、TDD-LTE(Cat 1) | |
Frequency band: N58 CA module (optional) | FDD-LTE:B1,B3,B5,B8 | |
Frequency band: N58 EA module (optional) | FDD-LTE:B1,B3,B5,B7,B8,B20,B28 | |
Frequency band: N58 LA module (optional) | FDD-LTE:B1,B2,B3,B4,B5,B7,B8,B28,B66 | |
1.1.3 GPS Performance | ||
Positioning type | GPS/BDS/GLONASS | |
Signal reception | Support GPS/BDS/GLONASS parallel reception and joint positioning | |
Cold start TTFF | ≤35S | |
Hot start TTFF | ≤1S | |
Recapture TTFF | ≤1S | |
Cold start capture sensitivity | -148 dBm | |
Hot start capture sensitivity | -156 dBm | |
Recapture sensitivity | -160 dBm | |
Tracking sensitivity | -162dBm | |
Positioning accuracy | ≤2M | |
Speed measurement accuracy | <0.1m/s | |
Timing accuracy | <30ns | |
Positioning update rate | Maximum 5Hz | |
AGPS | Support | |
2.1 Indicator Light Description | ||
Red LED (power/working status) | Status definition | |
Slow flash | Device is working normally | |
Always on | Device is charging | |
Off | Device is faulty or in sleep mode | |
Yellow LED (network communication signal light) | Status definition | |
Quick flash | Network is initializing | |
Slow flash | Network signal reception is normal | |
Off | No network signal is found or in sleep mode | |
Blue LED (GPS signal status) | Status definition | |
Quick flash | GPS signal is searching | |
Slow flash | GPS is located | |
Off | No GPS signal is found or in sleep mode | |
2.2 Functional Description | ||
Function details | Functional Description | |
Intelligent power saving mode | This mode uploads a heartbeat packet every 5 minutes, and a GPS positioning packet every 10 seconds and 100 meters when moving. The GPS enters sleep mode after 3 minutes of inactivity. | |
Interval mode | If set to 10 minutes, a heartbeat packet will be uploaded every 5 minutes, regardless of whether moving or stationary. A GPS positioning packet will be uploaded every 10 minutes. | |
Once a day mode | That is, the device will only work once at the specified time within 24 hours, and will enter the dormant state for the rest of the time (the device is in the shutdown state if it does not upload a heartbeat packet) | |
Disassembly alarm | When the light sensitivity changes from dark to bright, a disassembly alarm is triggered. | |
